LM386N DIP 4-12V 4mA Low Voltage Audio Amplifier

2SC2240: 120V, 100mA NPN Transistor (TO-92)

The 2SC2240 is a general-purpose NPN transistor designed for low-power amplification and switching applications. Encased in a TO-92 package, it is ideal for use in small signal circuits, consumer electronics, and other applications where a compact, reliable, and efficient transistor is needed. With a 120V maximum collector-emitter voltage and 100mA maximum collector current, the 2SC2240 is suitable for a wide range of low-power electronics requiring high voltage handling.

Key Features:

• Type: NPN Bipolar Junction Transistor (BJT)
• Voltage Rating (Vceo): 120V maximum collector-emitter voltage
• Current Rating (Ic): 100mA maximum collector current
• Package: TO-92, compact through-hole package ideal for tight PCB layouts
• High Gain (hFE): Typically provides high current gain (hFE) of around 200 to 600, making it efficient for small-signal amplification
• Low Saturation Voltage (Vce(sat)): Offers low power dissipation during switching
• Fast Switching: Suitable for applications requiring quick response times

Applications:

• Small Signal Amplification: Ideal for use in audio amplifiers, RF circuits, and other small signal processing applications.
• Switching Circuits: Suitable for low-current switching tasks like driving small relays or controlling low-power devices.
• Signal Processing: Can be used in communication systems, radios, and other consumer electronics for signal amplification and conditioning.
• Consumer Electronics: Used in applications such as TV circuits, radios, and other electronic devices where space-saving and efficiency are important.
• Voltage Regulation: Can be employed in low-power voltage regulation circuits.

Benefits:

• High Voltage Rating: With a 120V maximum collector-emitter voltage, the 2SC2240 can handle moderately high voltages, making it suitable for a variety of general-purpose applications.
• Compact Size: The TO-92 package allows for easy integration into small circuit designs, perfect for tight spaces on PCBs.
• Efficient Performance: High current gain and low saturation voltage make the 2SC2240 highly efficient for both amplification and switching.
• Cost-Effective: Offers an affordable solution for small-signal applications, ideal for consumer electronics, hobbyist projects, and low-power circuits.
• Reliable: Well-known for stable performance in a variety of low-power applications, ensuring long-term reliability.

The 2SC2240 is a reliable and versatile NPN transistor suitable for small signal amplification, low-power switching, and general-purpose applications in consumer electronics, communication devices, and more.

Package Included:

• 1 x LM386N DIP Low Voltage Audio Amplifier

Please note that the product image is for illustrative purposes only. The actual product may vary slightly in appearance.

Choose the LM386N for a reliable and efficient audio amplification solution in your electronic projects!
